Patented high temperature fire-resistant moulded wood-burning, beautiful and durable without replacement, increasing user convenience.
Decorative stone adopts high-temperature explosion-proof stone, which will not burst even under real fire and high temperature combustion, greatly improving safety.
The only 100% safe in the world
Remote segmented flame
Designated by Shining Building Business Co.,Ltd., European and American new fireplace mainstream, high-quality black piano paint.
No wood shaving or smell
Microcomputer precise energy control, automatic shutdown alarm for fuel shortage / leakage
Unit over-temperature automatic power-off protection
Circulating airflow regulates indoor / outdoor temperature and dehumidifies
Remote control or Manual switch
Natural gas (NG) or Barrel gas (LPG); 110v alternating current (AC)
Segmented flame
Unit Length 950↑ * Height 1010 * Depth 460mm
All adopt microcomputer control precision processing, noise-free unit
Size, flame, double-sided, single-sided, multi-sided design, upper and lower separation type can be adjusted according to customer needs
Unit 950↑ * 1010 * 460 mm
Decoration size (Length+10) * (Width+10) * (Depth + 10)
Single scheduled shutdown time 90 minutes
Forced exhaust fan YES
Voltage Alternating current 110V
Basic thermal power 100 cm long is BTU, and so on
Flame height 20~30 cm
Startup temperature Room temperature below 80°C
Fuel Natural gas (NG) or Barrel gas (LPG)
Microcomputer security monitoring YES
High temperature automatic power off protection YES
Protection against fuel leakage YES
Monfire monitoring YES
Remote control YES
Noise-free unit YES
Segmented real burning flame YES
Thermal method Circular airflow
Circulating airflow
Adjust indoor temperature
Dehumidification
Insulation materials (ex. Calcium silicate board) and high temperature resistant surface materials are required for building materials and decoration around the fireplace
110V single plug grounded socket and 6-minute gas tube (provided by hydropower) can be set up according to customer needs
An air circulation space must be left at the bottom or around the fireplace to supply the flames, and maintenance holes can be set to cut off gas and power separately.
The fire-glazed intelligent gas fireplace uses a two-stage mother fire set for fire. After the user starts the fireplace, the first mother fire source supplies a small amount of gas, and the igniter emits high-voltage current to ignite. After the microcomputer confirms that the fire source is stable, the gas flow is unlocked. Valve for main fire.
In case of unexpected flames due to instantaneous strong wind or unstable gas supply, the gas flow valve will automatically close immediately and return to the first ignition procedure to recover on its own.
In addition, there are built-in multiple sources of safety detection equipment such as fire source stability detection, temperature sensing, carbon monoxide concentration detection, and gas leakage detection. If the microcomputer senses an abnormal state, the gas flow valve is automatically closed and an alarm is issued for personnel to eliminate. After the situation, resume to use.
